electricty

3N-380V-50HZ, can be designed according to local voltage

Power(KW)

8.6KW

Rated cooling capacity

KW

23.26

Kcal/hr

2

compressor

brand

Copeland

type

closed

Start mode

Sequential direct start

Input power(KW)

7

condenser

mode

Efficient copper pipe sleeve corrugated aluminum fins

Cooling air volumem³/h

7025

Freon

type

R404A

Inner pump

Power(KW)

                    0.37

Lifting(meter)

28

Water pipe(mm)

32mm

evaporator

Water volue(m3/h)

4

Water pipe(mm)

32mm

Temperature control range ℃ and control accuracy

0--10

Safety protection device

High and low voltage switches, antifreeze protection, overload protection devices, coil overheat protection devices, temperature automatic protection switches, etc

Size of chilled water connection pipe

32mm

Outer size （mm）

length

1440

width

910

hegiht

900

weight

Kg

500
